stamax diamond tools co.,ltd
Products

Continuous Rim Turbo Blade

Continuous Rim Turbo Blade

Product name:Continuous Rim Turbo Blade

Item:

Details:

Continuous Rim Turbo Blade is designed for fast cutting with less chipping, better cooling and excellent dust removable. The wave shaped core improves blade rigidity, reduces friction, and avoid wobbling during cutting. Continuous rim turbo blade is applicable for reinforced concrete, hard concrete, hard brick, asphalt, tile wet or dry cutting, and for granite, marble, sandstone, limestone cutting. Continuous rim turbo blade has hot and cold press with 8mm segment with very fast and sooth cutting.
Features:
  • Universal dry or wet cutting blades
  •
  • Turbo teeth offer fast and smooth cutting
  • Application:

  • For reinforced concrete, hard concrete, hard brick, asphalt, tile wet or dry cutting
  • For granite, marble, sandstone, limestone cutting.
  •

    Item No.   Out Diameter   Arbor   Segment
    Thickness
      Segment
    Height

    Inch   mm   mm   mm   mm
    CRT105   4"   105   22.3 20 15.88   2.0   8
    CRT125   5"   125   22.3 20 15.88   2.2   8
    CRT150   6"   150   22.3 20 15.88   2.2   8
    CRT180   7"   180   DM22.315.88   2.4   8
    CRT200   8"   200   DM22.315.88   2.5   8
    CRT230   9"   230   25.4 22.3 20   2.5   8
    CRT300   10"   250   25.4 22.3 20   2.8   8
