金刚石工程钻筒

金刚石工程钻筒

产品名称:金刚石工程钻筒

产品编号:

详细说明:



DIAMOND DRILLING TOOLS

CHARACTERISTICS OF PRODUCTS

1.High efficiency,no-chipping,long life.

2.Selectable adaptor sizes: Dia6/8/10mm shank, M14 thread, 5/8”-11 thread or Gas 1/2” etc.

Product name

Dimension(mm)

Usable Length(mm)

Suggested

R.P.M

Plane Bits

6.0-6.5

40

4500

Plane Bits

8.0-9.0

40

4300

Plane Bits

10

40

4100

Plane Bits

12-16

40

3500-4000

Segment Bits

18

40-100

3500-4000

Segment Bits

19-32

40-100

3000-3500

Segment Bits

35-50

40-370

2500-2800

Segment Bits

51-100

40-370

1500-2500

Segment Bits

100-150

40-370

1500

Crown Bits

10-20

47

3500-4300

Crown Bits

20-35

47-370

3000-3500

Crown Bits

35-50

47-370

2500-2800

Crown Bits

50-60

47-370

2000-2500



CORE DRILL BITS

CHARACTERISTICS OF PRODUCTS

1.High effciency, long life and no breaking of segments.

2.Sizes of adaptor for threaded bit:M14,M16, G1/2",5/8"-11.

3.Applicable for drilling of brick wall,concrete, concrete with steel.

Type

Code

Description

(mm)

Spec

(mm)

Tooth

(Entries)

Usable

Length(mm)

Suggested

R.P.M

Feed Speed

(mm/min)

Core Drill Bit

CDB

19-22

10*3*10

3

40

3000-3500

70-90

Core Drill Bit

CDB

25

10*3*10

3

40

3000-3500

70-90

Core Drill Bit

CDB

30-32

10*3*10

3

40

3000-3500

70-90

Core Drill Bit

CDB

35-40

10*3*10

3

40

2000-2800

60-80

Core Drill Bit

CDB

45-50

10*3*10

3

40

2000-2800

50-60

Core Drill Bit

CDB

55

10*3*10

3

40

1500-2000

40-60

Core Drill Bit

CDB

60

10*3*10

3

40

1500-2000

40-60

Core Drill Bit

CDB

65

10*3*10

3

40

1500-2000

40-60

Core Drill Bit

CDB

70

10*3*10

3

40

1500-2000

40-60

Core Drill Bit

CDB

75-85

10*3*10

3

40

1500-2000

40-60

Core Drill Bit

CDB

90

10*3*10

3

40

1500-2000

40-60

Core Drill Bit

CDB

95-100

10*3*10

3

40

1000-1500

05-45

Core Drill Bit

CDB

125

10*3*10

3

40

1000-1500

25-45

Core Drill Bit

CDB

150

10*3*10

3

40

1000-1500

25-45



diamond core drill bit-diamond drilling tools

We are leading manufacturer of various drill bits, diamand bit, impregnated diamand bit, surface diamand bit, etc.

Our impregnated bits are manufactured to give optimum penetration rates and bit life, which is required to keep the cost of diamond drilling to a minimum.
The optimum diamond size, concentration and matrix type are dependent on the hardness and abrasiveness of the formation to be drilled. When order, please read.
